Binding Wire Annealing Furnace Manufacturer in India

Therm process Engineering Pvt. Ltd. designs and manufactures annealing furnaces for binding wire producers. Drawn MS wire is hard and springy. Annealing softens it so it can be twisted around reinforcement bars by hand without breaking. Therm process binding wire furnaces are designed for higher output per furnace, uniform temperature through the coil stack, long heating element life and low maintenance. A protected atmosphere can be supplied when a cleaner wire finish is required. Share your coil size and monthly output to discuss a furnace.

What Is a Binding Wire Annealing Furnace?

Binding wire is soft mild steel wire used to tie reinforcement bars together in concrete construction. It starts as wire rod, is drawn down to gauge, and becomes hard during drawing. Before it can be sold as binding wire, it must be annealed: heated to a temperature where the cold-worked structure recrystallises, held there, and cooled slowly.

A binding wire annealing furnace carries out this batch process on coils of drawn wire. The critical requirement is temperature uniformity through the coil stack. Wire at the core of a dense coil heats more slowly than wire at the surface. If the whole charge doesn't reach annealing temperature, some wire stays hard. Customers notice this immediately when the wire snaps during tying.

Furnace output per batch, cycle time, energy per tonne and element life decide the running cost of a binding wire plant.

Therm process Binding Wire Annealing Furnaces

Therm process designs its binding wire annealing furnaces around five practical priorities for wire producers:

• Higher output per furnace. The furnace design aims to maximise the tonnage processed in each cycle.
• Temperature uniformity. Even heating through the coil load gives consistent softness.
• Element life. Therm process states a two-year heating element life.
• Low maintenance. Designed for largely maintenance-free operation.
• User-friendly operation. Straightforward loading and cycle control.

A protected atmosphere can be supplied on demand for producers who want to limit surface oxidation during annealing. Therm process backs its furnaces with after-sales service. The company also manufactures bright annealing furnaces, strand annealers and bell furnace inner covers, so it can recommend the right approach for different wire products.

Technical Specifications

Key Features

• Designed for more tonnes per cycle.
• Uniform heating for consistent wire softness.
• Two-year element life.
• Maintenance-light design.
• Optional protected atmosphere.
• Operator-friendly controls.
• After-sales support.

How Binding Wire Annealing Works

• Loading Drawn wire coils are stacked in the furnace.
• Sealing The furnace is closed. If protected atmosphere is used, it is introduced at this point.
• Heating Elements raise the charge to annealing temperature.
• Soaking The load is held until the coil core reaches temperature and the wire recrystallises.
• Cooling The charge cools slowly to retain softness.
• Unloading and checking Coils are removed, and softness and ductility are checked.

Applications

• Annealing of MS binding wire for construction.
• Annealing of drawn MS wire for further processing.
• Soft wire for tying and packaging.

Industries Served

• Binding wire manufacturing
• Wire drawing units
• Construction wire products

Benefits

• Consistent wire softness, so fewer customer complaints about breakage.
• Higher throughput per furnace.
• Lower maintenance cost from long element life.
• Cleaner wire option with protected atmosphere.
• Custom Binding Wire Furnace Solutions

Share the following:

• Wire gauge range
• Coil weight and dimensions
• Monthly production target
• Required finish (standard or cleaner surface)
• Available power supply
• Shift pattern
• Plant space

Why Choose Therm process?

• Since 1997, Mumbai.
• Wire annealing specialist range: binding wire furnaces, strand annealers, bright annealing furnaces.
• After-sales service support.
• ISO 9001 & ISO 14001 certified, as stated by the company.

Related Therm process Products

• Bright Annealing Furnace
• Strand Annealer
• Bell Furnace Inner Cover
• Roller Hearth Annealing Furnace
