Micro - Valve |
|
|
|
|
|
| |
|
 |
THERM-PROCESS "state of art"
Micro Valve is a well factory
calibrated device for controlling
oil flow to burner. The precise
flow control is achived through
the rotation of a piston with
a wide movement of the operating
handle.
The valve can be used as a tight
shut-off for oil, however is
not recommended as microvalve
setting gets disturbed every
time while shutting off the
burner.Hence we always recommend
to use additional shut-off valve
in the line. |
|
| |
t
is simple & rugged in construction
(only one moving part), accurately
made & dependable.
The valve can be provided with electrical
actuator for auto control of air to
oil ratio.
The valve internals can be used easly
inspected & attached without removing
valve from the pipe line. |
| |
 |
| |
| Specification
: |
| |
| Oil
Type |
LDO
/ HSD / LSHS /
Fo. |
| Oil
Temp. |
145 0 C
(Max). |
| Oil
Inlet Pressure |
5.0
Kg / cm2 (Max) |
| Size |
3/8"
BSP |
|
|
| Capacity
: |
| |
| Sr.
No. |
Oil
Capacity at #
7 ^ P0.7 bar |
| 18
- 01 |
15
LPH |
| 18
- 02 |
30
LPH |
| 18
- 03 |
60
LPH |
| 18
- 04 |
120
LPH |
|
|
| |
|
|
-
To
calculate flow at different pressures,
determine required flow &
available pressure drop. Using
square root method find out flow
at 0.7 bar & select nearest
Micro Valve.
-
Contact THERM-PROCESS for Micro Valve coupled with electrical
actuctot to achieve automatic
air oil ratio.
|
|
| |
|
| |
|
| |
